| DD11 EN 10111 Number: 1.0332 | Comparison of steel grades | |
| UNI5867 | FEP11 | |
| DIN1614 | STW22 | |
| NFA 36-301 | 1C | |
| JIS G 3131 | SPHD | |
| ASTM-SAE | A621DQ-SAE1010 | |
| BS1449 | HR3 | |
| UNE36.093 | AP11 | |
| Chemical elements | C | Si max |
Mn max | P max. |
S max. |
| %,by mass | 0.12 | -- | 0.60 | 0.045 | 0.045 |
Mechanical properties
| thickness | Yield StrengthReH [N/mm2] transv.min. |
TensileStrengthRm [N/mm2]transv. |
Fracture Elongation[%]transv. min. | BendingTesttransv. bendingmandrel Øangle = 180°s = plate thickness |
| t≤ 16mm t >16mm | 170-340 | 1 S | ||
|
t < 3mm
t ≥ 3mm
|
440 | |||
|
Up to 1.5mm
1.51-2.00mm
2.01-2.50mm
2.51-2.99mm
≥ 3mm
|
23 A80 24 A80 28 A5 |
