Weldable normalized fine grained pressure vessel steels

Weldable normalized fine grained pressure vessel steels

Weldable normalized fine grained pressure vessel steels

Weldable normalized fine grained pressure vessel steels

ASTM , EN  Weldable normalized fine grained pressure vessel steels,Weldable normalized fine grained pressure vessel steels plate, Weldable normalized fine grained pressure vessel steels sheet, Weldable normalized fine grained pressure vessel steels coil, Weldable normalized fine grained pressure vessel steels supplier

Weldable normalized fine grained pressure vessel steels description
The fine grained pressure vessel steels grades rolled under normalised conditions offer good cold-forming and hot-forming properties without negatively affecting the material properties. These steel grades are therefore also suitable for cold-bordering and cold-flanging as well as for cold-bending and cold-folding, considering the bending radii according to DIN 6935 for a steel grade of corresponding strength. With coldforming above 5% or hot-forming outside of the temperature range of 850 - 1.000 °C as well as after excess times, the steels rolled under normalised conditions should be subsequently normalised at 900 - 950 °C. The holding time after temperature equalisation should be approx. 1 minute per millimetre of plate thickness.

Weldable normalized fine grained pressure vessel steels Application
These fine-grain pressure vessel steel grades are characterised by a minimum yield strength of 275 - 460 MPa, by good weldability and high resistance to brittle cracking. These grades are used above all for manufacturing vessels for pressurised gas (LPG, butane and propane tanks), pressure vessels, steam boiler parts, pressure piping, compressors etc.
The following special grades are available for extraordinary applications:
P...NL1 and P...NL2 or P...ML1 and P...ML2 for application temperatures below -20 °C;
P...NH for operating temperatures of up to 400 °C.
The user of these steel grades must make sure that his calculation, design and processing methods are appropriate for the material. The welding technique used must be suitable for the intended application and comply with the state-of-the-art.

The main grade of  Weldable normalized fine grained pressure vessel steels are :
Material #: 1.0486, 1.0487, 1.0488, 1.1104, 1.0562, 1.0565, 1.0566, 1.1106.
EN 10028-3: P275N,P275NH , P275NL1, P275NL2, P355N, P355NH, P355NL1, P355NL2.
DIN 17102: StE 285, WStE 285, TStE 285, EStE 285, StE 355, WSteE 355, TStE 355, EStE 355.
NFA 36-207 : A 510 AP, A 510 AP, A 510 FP 1.
UNI 7382 : Fe E 355 KG, Fe E 355-2, Fe E 355-3.
BS 1501: 224 Gr. 400, 224 Gr. 430, 223 Gr. 490, 224 Gr. 490, 225Gr. 490
UNE 36081: AE 355 KG
ASTM: A 516 Gr. 60, A 662 Gr. A, A 537 CL 1, A 662 Gr. C, A 737 Gr. B

Weldable normalized fine grained pressure vessel steels equivalent grades

Material #

EN 10028-3

DIN 17102

NFA 36-207

UNI 7382

BS 1501

UNE 36081

ASTM

1.0486

P275N

StE 285





224 Gr. 400





1.0487

P275NH

WStE 285





224 Gr. 430



A 516 Gr. 60

1.0488

P275NL1

TStE 285









A 662 Gr. A

1.1104

P275NL2

EStE 285











1.0562

P355N

StE 355

A 510 AP

Fe E 355 KG

223 Gr. 490

AE 355 KG

A 537 CL 1

1.0565

P355NH

WSteE 355

A 510 AP

Fe E 355-2

224 Gr. 490



A 662 Gr. C

1.0566

P355NL1

TStE 355

A 510 FP 1

Fe E 355-3

224 Gr. 490



A 737 Gr. B

1.1106

P355NL2

EStE 355











Weldable normalized fine grained pressure vessel steels Supply Size
Thickness: 8mm to 200mm
Width: 1500mm to 4200mm
Length: 2000mm to 18000mm

Weldable normalized fine grained pressure vessel steels Delivery state
Hot Rolled, Cold Rolled, Normalized, Quenched, Tempering, Thermal Mechanical Control Process (TMCP), Electroslag Remelting Technical, HIC test.

Weldable normalized fine grained pressure vessel steels Services
Cutting, Painting, shot blast, and The third party inspection in DNV, BV, LR, GL, ABS, CCS , SGS, and others in super thick ship steel plate.

Weldable normalized fine grained pressure vessel steels Chemical composition

Grade

C

Si

Mn

P

S

N

Altotal

Cu

Ni

Ti

V

Nb



max.

max.



max.

max.

max.

min.

max.

max.

max.

max.

max.

P275NH 2)5)

0,16

0,40

0,804)- 1,50

0,025

0,015

0,012

0,0201)

0,30

0,50

0,03

0,05

0,05

P275NL12)5)

0,16

0,40

0,804)- 1,50

0,025

0,015

0,012

0,0201)

0,30

0,50

0,03

0,05

0,05

P275NL22)5)

0,16

0,40

0,804)- 1,50

0,020

0,010

0,012

0,0201)

0,30

0,50

0,03

0,05

0,05

P355N2)6)

0,18

0,50

1,10 - 1,70

0,025

0,015

0,012

0,0201)

0,30

0,50

0,03

0,10

0,05

P355NH2)6)

0,18

0,50

1,10 - 1,70

0,025

0,015

0,012

0,0201)

0,30

0,50

0,03

0,10

0,05

P355NL12)6)

0,18

0,50

1,10 - 1,70

0,025

0,015

0,012

0,0201)

0,30

0,50

0,03

0,10

0,05

P355NL22)6)

0,18

0,50

1,10 - 1,70

0,020

0,010

0,012

0,0201)

0,30

0,50

0,03

0,10

0,05

P355M2)

0,14

0,50

≤ 1,60

0,025

0,020

0,015

0,0207)

8)

0,50

0,053)

0,103)

0,053)

P355ML12)

0,14

0,50

≤ 1,60

0,020

0,015

0,015

0,0207)

8)

0,50

0,053)

0,103)

0,053)

P355ML22)

0,14

0,50

≤ 1,60

0,020

0,015

0,015

0,0207)

8)

0,50

0,053)

0,103)

0,053)

P420M2)

0,16

0,50

≤ 1,70

0,025

0,020

0,0207)

0,0207)

8)

0,50

0,053)

0,103)

0,053)

P420ML12)

0,16

0,50

≤ 1,70

0,020

0,015

0,0207)

0,0207)

8)

0,50

0,053)

0,103)

0,053)

P420ML22)

0,16

0,50

≤ 1,70

0,020

0,015

0,0207)

0,0207)

8)

0,50

0,053)

0,103)

0,053)

P460M2)

0,16

0,60

≤ 1,70

0,025

0,020

0,0207)

0,0207)

8)

0,50

0,053)

0,103)

0,053)

P460ML12)

0,16

0,60

≤ 1,70

0,020

0,015

0,0207)

0,0207)

8)

0,50

0,053)

0,103)

0,053)

P460ML22)

0,16

0,60

≤ 1,70

0,020

0,015

0,0207)

0,0207)

8)

0,50

0,053)

0,103)

0,053)


1) If N is additionally fixed by means of Nb, Ti or V, the minimum Al content is not determined.
    If N is only fixed with Al, then: Al/N ≥ 2.
2) Cr ≤ 0,30 %, Mo ≤ 0,08 %, Cr + Cu + Mo ≤ 0,45 %
3) Nb + V + Ti ≤ 0,15%
4) For thicknesses < 6.0 mm, aminimum content for Mn 0.60% is permitted.
5) Nb + V + Ti ≤ 0,05%
6) Nb + V + Ti ≤ 0,12%
7) The minimum value for Altotal does not apply if sufficient amounts of other nitrogen-fixing elements are present.

A carbon equivalent value

CE = C + Mn/6 + (Cr + Mo + V)/5 + (Cu + Ni)/15

may be agreed in the order, i.e. 0,40%  max. for grades P275N, 0,43%  for grades P355N, 0,39%  for grades P355M, 0,43%  for grades P420M and 0,45%  for grades P460M.
8) (Cr + Cu + Mo) ≤ 0,60%

Weldable normalized fine grained pressure vessel steels Mechanical properties

Grade

Min. yield strength

Tensile strength

Min. total elongation [%]



MPa

MPa





e2) ≤ 16

e2) > 16





P275NH

275

265

390 - 510

24

P275NL1

275

265

390 - 510

24

P275NL2

275

265

390 - 510

24

P355N

355

345

490 - 630

22

P355NH

355

345

490 - 630

22

P355NL1

355

345

490 - 630

22

P355NL2

355

345

490 - 630

22

P355M

355

450 - 610

22

P355ML1

355

450 - 610

22

P355ML2

355

450 - 610

22

P420M

420

400

500 - 660

19

P420ML1

420

400

500 - 660

19

P420ML2

420

400

500 - 660

19

P460M

460

440

530 - 720

17

P460ML1

460

440

530 - 720

17

P460ML2

460

440

530 - 720

17


1) Transverse samples
2) Nominal thickness e [mm]

Bebon International is a global steel supply and stockholding company. Partnerships integrating the resources of the China’s most technically advanced steel mills enable Bebon International to provide a single competitive source for the distribution of steel products worldwide.

Bebon International offer premium quality Weldable normalized fine grained pressure vessel steels Plates. These Weldable normalized fine grained pressure vessel steels plates have consistent and controlled properties, designed for withstanding the high pressure for pressurised gas etc..

Bebon International has one of the widest steel plate product ranges in the world. Whether you are a designer, contractor or fabricator you will find our product range both modern and extensive. Weldable normalized fine grained pressure vessel steels offered by Bebon is in very high quality to support the requirements of those engaged in large projects.
