RINA AH36

RINA AH36 shipbuilding steel plate; RINA AH36 shipbuilding sheet; RINA AH36 shipbuilding plate supplier; RINA AH36 shipbuilding plate price; RINA AH36 hull structure steel; RINA AH36 shipbuilding plate property.

RINA AH36 shipbuilding steel

RINA AH36 steel plate/sheet for shipbuiling&platform. The shipbuilding steel plate grade AH36 is the high tensile strength steel. RINA AH36 steel is the Hull structural steel, with it's good toughness properties, higher strength,strong corrosion-resistance,the processing properties,and welding properties.

RINA AH36 shipbuilding steel Application range

As the super features of RINA AH36 shipbuilding steel, RINA AH36 steel plate/sheet can be used in the manufacture of the ship's hull structure, and usually do navigation around coastal and river area. Also, RINA AH36 shipbuilding steel is widely used in oil platform and offshore platform.

RINA AH36 shipbuilding steel supply size
Thickness: 4mm-260mm

Width: 1200mm-4000mm
Length: 3000mm-18000mm
(other plate sizes and thicknesses are available on request)

RINA AH36 shipbuilding steel composition (%)

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max	Nb	V
AH36	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08	0.02-0.05	0.05-0.10

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be: ≤0.38%(thickness ≤ 50mm),≤0.40%( when the thickness >50-100). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

RINA AH36 shipbuilding steel mechanical property

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
AH36	490-630	355	21	E.T °C	Thickness (mm)
				0	≤ 50		>50-70		>70-100
					L	C	L	C	L	C
					34	24	41	27	50	34

Note: In the list , Rm: tensile strength, Re: Yield strength, A%: elongation, E.T: experimental temperature, L: lengthways, C: crosswise.

RINA AH36 shipbuilding steel deliver condition

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
AH36	Nb+V or V	Plate/ sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/ sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be: ≤0.36% (thickness≤50mm), ≤0.38%(when the thickness >50-100). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

Henan BEBON international co.,ltd is an outstanding and professional RINA AH36 shipbuilding steel exporter and stockist in china. Based on our huge productive ability, RINA AH36 shipbuilding steel stock is available, so if you have any need of RINA AH36 shipbuilding steel, we also can meet your maximum request. Welcome to call or email us for you need.
