EN10025-2 S235JR carbon steel plate is a low carbon, high tensile strength structural steel which can be readily welded to other weldable steel. With low carbon equivalent, S235JR Steel possesses good cold-forming properties. S235JR plate is produced by fully killed steel process and supplied in normalized or controlled rolling condition. S235JR carbon steel plates are widely used in the engineering and construction industries.
EN10025-2 S235JR Steel Plate Specification:
Thickness: 2-700mm
Width: 1220-4200mm
Length:5000-18000mm
EN10025-2 S235JR Carbon Steel Plate Chemical Composition:
| Chemical elements | C≤ 16mm max | C>16mm max | Si max | Mn max | P max. | S max. |
| %, by mass | 0.17 | 0.20 | - | 1.40 | 0.045 | 0.045 |
EN10025-2 S235JR Carbon Steel Plate Mechnical Property:
| Thickness (mm) | |||||||||
| S235JR | ≤ 16 | > 16 ≤ 40 | > 40 ≤ 63 | > 63 ≤ 80 | > 80 ≤ 100 | > 100 ≤ 150 | > 150 ≤ 200 | > 200 ≤ 250 | > 250 |
| Yield strength (≥Mpa) | 235 | 225 | 215 | 215 | 215 | 195 | 185 | 175 | 175 |
| < 3 | ≥ 3 ≤ 100 | > 100 ≤ 150 | > 150 ≤ 250 | > 250 | |||||
| Tensile strength (Mpa) | 360-510 | 360-510 | 350-500 | 340-490 | 340-490 | ||||
EN10025-2 S235JR carbon steel plates are widely used in Structural application in freight cars, transmission towers, dump trucks, cranes, trailers, bull dozers, excavators, forestry machines, railway wagons, penstocks, highway bridges, building structures, oil and gas platforms, offshore structures, shipbuilding, power plant, palm oil equipments and machineries, fans, pumps, lifting equipments and port.
As a EN10025-2 S235JR carbon steel plate supplier in China, BBN steel keeps more than 1000 tons S235JR steel plates in stock every month. Any need in S235JR steel, please contact us!
Just like you, 70% customers choose long-term cooperation with BBN steel not only for our good product and service quality, good reputation in the international market, but also for our experienced one-stop raw material supply and further steel processing!
