DIN 17155 HI Pressure Vessel And Boiler Steel Plate

DIN 17155 HI Pressure Vessel And Boiler Steel Plate

DIN 17155 HI Pressure Vessel And Boiler Steel Plate Chemical Composition and Mechanical Property

Grade C% SI% Mn% P%, max S%, max Al% Cr% Cu%, max Mo% Nb%, max Ni%, max Ti%, max V%, max
 HI ≤O.16 ≤O.35 0.4-1.2 0.035 0.03 ≥0.020 ≤O.25 0.3 ≤O.10 0.01 0.3 0.03 0.03
Steel Grade Thickness, in mm Yield Strength, min Tensile Strength Elongation, %, min
 HI T≤16 235 360-480 24
16<T≤40 225
40<T≤60 215
60<T≤100 200 360-480 23
100<T≤150 185 350-480



DIN 17155 HI Pressure Vessel And Boiler Steel Plate Application

DIN 17155 HI Pressure Vessel And Boiler Steel Plate are used in Pressure Vessel,Boiler,Storage Tanks and Heat Exchanger in Oil,Gas Project.

DIN 17155 HI Pressure Vessel And Boiler Steel Plate Other Name

DIN 17155 HI Boiler steel plate,DIN 17155 HI Pressure Vessel Steel plate, DIN 17155 HI Storage Tanks Steel plate. DIN 17155 HI Heat Exchanger Steel Plate .

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
