SEW092 QStE380N Automobile structure steel plate
SEW092 QStE380N Automobile structure steel plate Chemical Composition and Mechanical Property
| Grade | C % | Si % | Mn % max. | P % | S % | Al % min. | Nb % max | Ti % max |
| QStE380N | 0.18 | 0.50 | 1.60 | 0.03 | 0.03 | 0.015 | 0.09 | 0.22 |
| Grade | Yield Strength N/mm² mind. |
Tensile Strength N/mm² |
Elongation % | Technology bending test Mandrel diameter Da = Sample thickness bending angle180° |
|||
| Thickness＜3mm | ≥3mm≤6mm | ≥3mm | |||||
| L0= 80mm | L0= 50mm | L0= 50mm | L0= 5d0 | ||||
| QStE380N | 380 | 500bis640 | 19 | 21 | 23 | 25 | D=0.5a |
SEW092 QStE380N Automobile structure steel plate Application
QStE380N steel plate is widely used in automotive industry, machinery manufacturing industry, with zero processing industry, the motorcycle industry, hardware accessories.
SEW092 QStE380N Automobile structure steel plate Other Name
SEW092 QStE380N steel plate, QStE380N Automobile structure steel plate
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
