JIS G3125-2004 SPA-H Weather Resistant Steel Coil

JIS G3125-2004 SPA-H Weather Resistant Steel Coil Chemical Composition and Mechanical Property

Grade

The Element Max (%)

C max.

Si

Mn max.

P

S max.

Cu

Cr Ni  max.

SPA-H

0.12

0.20-0.75

0.6

0.070-0.150

0.035

0.25-0.55

0.30-1.25 0.65

Grade



Thickness

Yield

Tensile

Elongation

SPA-H

mm

Min Mpa

Min. Mpa

Min  %

t≦6.0

355

490

22

T>6.0

355

490

15



JIS G3125-2004 SPA-H Weather Resistant Steel Coil Application

JIS G3125-2004 SPA-H weather resistant steel coil is used for Vehicle, Bridge, Tower and Containers.

JIS G3125-2004 SPA-H Weather Resistant Steel Coil Other Name

SPA-H weather resistant steel coil, JIS G3125-2004 SPA-H weather resistant steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
