JIS G3106 SM570 Carbon and Low-alloy High-strength Steel Coil
JIS G3106 SM570 Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property
|
C max |
Si max |
Mn max |
P max |
S max |
|
0.18 |
0.55 |
1.60 |
0.035 |
0.035 |
| Yield Strength (MPa) min. (t≤16mm) | Yield Strength (MPa) min.(16mm<t≤25.4mm) | Tensile Strength (MPa) (t≤25.4mm) | Elongation % min. (t≤16mm) | Elongation % min. (16mm<t≤25.4mm) |
| 460 | 450 | 570～720 | 19 | 26 |
JIS G3106 SM570 Carbon and Low-alloy High-strength Steel Coil Application
JIS G3106 SM570 structural steel, SM570 carbon steel coil, SM570 structural steel coil
JIS G3106 SM570 Carbon and Low-alloy High-strength Steel Coil Other Name
JIS G3106 SM570 structural steel, SM570 carbon steel coil, SM570 structural steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
