JIS G3106 SM400C Carbon and Low-alloy High-strength Steel Coil

JIS G3106 SM400C Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property

C max

Si max

Mn max

P max

S max

0.18

0.35

1.40

0.035

0.035

Yield Strength (MPa) min. (t≤16mm) Yield Strength (MPa) min.(16mm<t≤25.4mm) Tensile Strength (MPa) (t≤25.4mm) Elongation % min. (t≤5mm) Elongation % min. (5mm<t<16mm) Elongation % min. (16mm<t≤25.4mm)
245 235 400-510 23 18 22

JIS G3106 SM400C Carbon and Low-alloy High-strength Steel Coil Application

SM400C carbon steel coil is used in the Construction of Bridges, Highway Construction and Other Engineering construction.

JIS G3106 SM400C Carbon and Low-alloy High-strength Steel Coil Other Name

JIS G3106 SM400C structural steel, SM400C carbon steel coil, SM400C structural steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
