JIS G3132-2011 SPHT2 Pipeline Steel Coil
JIS G3132-2011 SPHT2 Pipeline Steel Coil Chemical Composition and Mechanical Property
|
Grade |
C |
Si |
Mn |
P |
Al |
S |
|
SPHT2 |
≤0.18 |
≤0.35 |
≤0.50 |
≤0.040 |
≥0.020 |
≤0.040 |
|
Grade |
Tensile Test |
180°BendingTestbDiameter |
|||||
|
Rm (MPa) |
Elongation (%) |
||||||
|
Nominal Thickness(mm) |
Nominal Thickness(mm) |
||||||
|
<1.6 |
1.6~<3.0 |
3.0~<6.0 |
6.0~≤13.0 |
≤3.0 |
>3.0 |
||
|
SPHT2 |
≥340 |
≥25 |
≥27 |
≥30 |
≥32 |
2a |
3a |
JIS G3132-2011 SPHT2 Pipeline Steel Coil Application
JIS G 3132-2011 SPHT2 pipeline steel coil is used in Oil and Gas Project.
JIS G3132-2011 SPHT2 Pipeline Steel Coil Other Name
JIS G 3132 pipeline steel coil, JIS G3132 SPHT2 pipeline steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
