EN10025-3 S420N Carbon and Low-alloy High-strength Steel Coil

EN10025-3 S420N Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property

C max

Si max.

Mn

P max

S max

Nb max.

V max.

Al max

Ti max

Cr max

Ni max

Mo max

Cu max

N max

0.20

0.60

1.00-1.70

0.030

0.025

0.05

0.20

0.02

0.05

0.30

0.80

0.10

0.55

0.025

Yield Strength (MPa) min. (t≤16mm) Yield Strength (MPa) min.(16mm<t≤25.4mm) Yield Strength (MPa) (t≤25.4mm) Elongation % min. (t≤25.4mm)
420 400 520-680 19

EN10025-3 S420N Carbon and Low-alloy High-strength Steel Coil Application

S420N carbon steel coil is used in the Construction of Bridges, Highway Construction and Other Engineering construction.

EN10025-3 S420N Carbon and Low-alloy High-strength Steel Coil Other Name

EN10025-3 S420N structural steel, S420N carbon steel coil, S420N structural steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
