DIN 17155 19Mn6 Steel Coil for Gas Vessels

DIN 17155 19Mn6 Steel Coil for Gas Vessels Chemical Composition and Mechanical Property

C

Si

Mn

P max.

S max.

Al min. Cr max. Cu max. Mo max. Nb max. Ni max.

Ti max.

V max.

0.15-0.22

0.15-0.60

1.00-1.60

0.035

0.030

0.020 0.25 0.30 0.10 0.01 0.30

0.03

0.03

Yield Strength (MPa) min. (t≤16mm) Yield Strength (MPa) min. (16mm<t≤25.4mm) Tensile Strength (MPa) Elongation % min.
355 345 510-650 20

DIN 17155 19Mn6 Steel Coil for Gas Vessels Application

DIN 17155 19Mn6 steel coil is mainly used for gas cylinders and gas vessels.

DIN 17155 19Mn6 Steel Coil for Gas Vessels Other Name

DIN 17155 19Mn6 steel coil, DIN 17155 19Mn6 steel coil for gas cylinders, DIN 17155 19Mn6 steel coil for gas vessels

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
