DIN 17102 StE500 Hot Rolled Steel Coil

DIN 17102 StE500 Hot Rolled Steel Coil Chemical Composition and Mechanical Property

C max

Si

Mn

P max

S max

N max.

All tot 1)

Cr max

Cu max

Mo max

Ni max

Nb max

Ti max

V max

Nb+Ti+V max

0.21

0.10-0.60

1.00-1.70

0.035

0.030

0.020

0.020

0.30

0.20

0.10

1.00

0.05

-

 0.22

0.22

1) If nitrogen is additionally controlled by niobium, titanium or vanadim, the specification minimum aluminium content is dropped.

Yield Strength (MPa) min. (t≤16mm) Yield Strength (MPa) min.(16mm<t≤25.4mm) Tensile Strength (MPa) Elongation % min.
500 480 610-780 18

DIN 17102 StE500 Hot Rolled Steel Coil Application

DIN 17102 StE500 hot rolled steel coil is mainly used for Automobile Frame, Construction of Bridges, Highway Construction and Other Engineering construction.

DIN 17102 StE500 Hot Rolled Steel Coil Other Name

DIN 17102 StE500 hot rolled steel, DIN 17102 StE500 hot rolled steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
