DIN 17102 WStE460 Carbon and Low-alloy High-strength Steel Coil
DIN 17102 WStE460 Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property
|
C max |
Si |
Mn |
P max |
S max |
N max. |
All tot 1) |
Cr max |
Cu max |
Mo max |
Ni max |
Nb max |
Ti max |
V max |
Nb+Ti+V max |
|
0.20 |
0.10-0.60 |
1.00-1.70 |
0.035 |
0.030 |
0.020 |
0.020 |
0.30 |
0.20 |
0.10 |
1.00 |
0.05 |
- |
0.20 |
0.22 |
1) If nitrogen is additionally controlled by niobium, titanium or vanadim, the specification minimum aluminium content is dropped.
| Yield Strength (MPa) min. (t≤16mm) | Yield Strength (MPa) min.(16mm<t≤25.4mm) | Tensile Strength (MPa) | Elongation % min. |
| 460 | 450 | 560-730 | 17 |
DIN 17102 WStE460 Carbon and Low-alloy High-strength Steel Coil Application
WStE460 carbon steel coil is used in the Construction of Bridges, Highway Construction and Other Engineering construction.
DIN 17102 WStE460 Carbon and Low-alloy High-strength Steel Coil Other Name
WStE460 carbon steel coil, WStE460 structural steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
