DIN 17102 TStE255 Carbon and Low-alloy High-strength Steel Coil

DIN 17102 TStE255 Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property

C max

Si max.

Mn

P max

S max

N max.

All tot 1)

Cr max

Cu max

Mo max

Ni max

Nb max

Ti max

V max

Nb+Ti+V max

0.16

0.40

0.50-1.30

0.030

0.025

0.020

0.020

0.30

0.20

0.08

0.30

0.03

-

 -

0.05

1) If nitrogen is additionally controlled by niobium, titanium or vanadim, the specification minimum aluminium content is dropped.

Yield Strength (MPa) min. (t≤16mm) Yield Strength (MPa) min.(16mm<t≤25.4mm) Tensile Strength (MPa) Elongation % min.
255 245 360-480 25

DIN 17102 TStE255 Carbon and Low-alloy High-strength Steel Coil Application

TStE255 carbon steel coil is used in the Construction of Bridges, Highway Construction and Other Engineering construction.

DIN 17102 TStE255 Carbon and Low-alloy High-strength Steel Coil Other Name

DIN 17102 TStE255 structural steel, TStE255 carbon steel coil, TStE255 structural steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
