ASTM A709/A709M Grade 50S Carbon and Low-alloy High-strength Steel Coil

ASTM A709/A709M Grade 50S Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property

C max Si max Mn P max S max V max Nb Cu max Ni max Cr max Mo max

0.23

0.40

0.50-1.60

0.04-35

0.045

0.15 0.05 0.60 0.45 0.35 0.15
Grade Yield Strength (MPa) min. Tensile Strength (MPa) min. Elongation in 8 in. min. % Elongation in 2 in. min. %

A709 Gr.50S

345 450 18 21

ASTM A709/A709M Grade 50S Carbon and Low-alloy High-strength Steel Coil Application

A709 Grade 50S high-strength low-alloy structural steel coil is suited in the Construction of Bridges, Highway Construction and Other Engineering construction.

ASTM A709/A709M Grade 50S Carbon and Low-alloy High-strength Steel Coil Other Name

ASTM A709/A709M high-strength low-alloy structural steel, A709 Grade 50S carbon steel coil, A709 Grade 50S high-strength low-alloy structural steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
