ASTM A709/A709M Grade 100 Carbon and Low-alloy High-strength Steel Coil

ASTM A709/A709M Grade 100 Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property

Grade

Chemical Composition(%)

C

Mn

Si

P

S

A709Grade 100

0.26

0.4-0.9

0.4

0.04

0.05

Grade

Mechanical Property



Tensile Strength(MPa)

Yield Strength(MPa)

% Elongation in 2 in.(50mm) min

Impacting Test  Temperature(°C)



A709Grade 100

400-650

250

20

+20,0,-20



Grade C Mn P S Si Cu
A709 HPS 100W ≤0.08 0.95-1.50 ≤0.015 ≤0.006 0.15-0.50 0.90-1.20
Ni Cr Mo V Al N Nb
0.65-0.90 0.4-0.65 0.4-0.65 0.04-0.08 0.02-0.05 ≤0.015 0.01-0.03
Grade Thickness Yield
Strength
Tensile
Strength
Elongation Charpy V Impact Test
Degree Energy 1 Energy 2
A709 HPS 100W mm Min Mpa  Mpa Min  % - J J
5<t≤300 690 760-895 18

ASTM A709/A709M Grade 100 Carbon and Low-alloy High-strength Steel Coil Application

A709 Grade 100 carbon steel coil is suited in the Construction of Bridges, Highway Construction and Other Engineering construction.

ASTM A709/A709M Grade 100 Carbon and Low-alloy High-strength Steel Coil Other Name

ASTM A709/A709M high-strength low-alloy steel, A709 Grade 100 carbon steel coil, A709 Grade 100 high-strength low-alloy structural steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
