ASTM A514/A514M Grade S Carbon and Low-alloy High-strength Steel Coil
ASTM A514/A514M Grade S Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property
|
Grade |
C |
Mn |
P |
S |
Si |
Ti |
Mo |
B |
V |
Nb |
|
ASTM A514 Grade S |
0.11-0.21 |
1.10-1.50 |
0.035 |
0.02 |
0.15-0.45 |
B |
0.10-0.60 |
0.001-0.005 |
0.06 |
0.06 |
|
Steel thickness in.(mm) |
yield strength ksi(MPa) |
Tensile strength ksi(MPa) |
2in.(50mm) elongation % |
|
≤0.75(20) |
100（690）v |
110-130（760-895） |
18 |
|
>0.75-2.5（20-65） |
100（690） |
110-130（760-895） |
18 |
|
>2.5-6（65-150） |
90（620） |
100-130（690-895） |
16 |
ASTM A514/A514M Grade S Carbon and Low-alloy High-strength Steel Coil Application
ASTM A514/A514M carbon steel is used in Construction of Bridges, Highway Construction and Other Engineering construction.
ASTM A514/A514M Grade S Carbon and Low-alloy High-strength Steel Coil Other Name
ASTM A514/A514M Low-alloy High-strength Steel, A514/A514M Grade S carbon steel coil, A514/A514M Grade S Low-alloy High-strength Steel Coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
