ASTM A514/A514M Grade C Carbon and Low-alloy High-strength Steel Coil
ASTM A514/A514M Grade C Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property
| Grade | C | Mn | P | S | Si | Ni | Cr | Mo | V | Ti | Cu | Co | B | Zr |
| A514 Gr.C |
0.10-0.20 | 1.1-1.50 | 0.035 | 0.04 | 0.15-0.30 | - | - | 0.20-0.30 | - | - | - | - | 0.001-0.005 | - |
| Grade | Thickness (mm) |
Tensile strength .ksi [MPa] |
Yield strength Min ksi [MPa] |
Elongation in under 50mm,min by % | Hardness HBW |
| A514Gr.C | ≤20 20-65 |
760-895 760-895 |
690 690 |
18 18 |
235-293 |
ASTM A514/A514M Grade C Carbon and Low-alloy High-strength Steel Coil Application
A514/A514M Grade C carbon steel is used in Construction of Bridges, Highway Construction and Other Engineering construction.
ASTM A514/A514M Grade C Carbon and Low-alloy High-strength Steel Coil Other Name
A514/A514M Grade C carbon steel coil, A514/A514M Grade C Low-alloy High-strength Steel, ASTM A514/A514M Low-alloy High-strength Steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
