ASTM A514/A514M Grade B Carbon and Low-alloy High-strength Steel Coil
ASTM A514/A514M Grade B Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property
| A514 Grade B | The Element Max (%) | ||||||||||||||
| C | Mn | P | S | Si | Ni | Cr | Mo | V | Ti | Zr | Cu | B | Nb | ||
| 0.12-0.21 | 0.70-10-.00 | 0.035 | 0.04 | 0.20-0.35 | - | 0.40-0.65 | 0.15-0.25 | 0.03-0.08 | 0.01-0.03 | - | - | 0.00050.005 | - | ||
| Grade | Thickness (mm) |
Tensile strength .ksi [MPa] |
Yield strength Min ksi [MPa] |
Elongation in under 50mm,min by % | Hardness HBW |
| A514Gr.B | - | 110-130 ksi | 100 ksi, min | 16 in 2 inch | 235-293 |
ASTM A514/A514M Grade B Carbon and Low-alloy High-strength Steel Coil Application
ASTM A514/A514M Grade B Carbon steell is used in Construction of Bridges, Highway Construction and Other Engineering construction.
ASTM A514/A514M Grade B Carbon and Low-alloy High-strength Steel Coil Other Name
ASTM A514/A514M Low-alloy High-strength Steel Coil, A514/A514M Grade B Carbon steel, ASTM A514/A514M Carbon steel coil
Additional Condition
UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
Other Terms
Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
