ASME SA709/SA709M Grade HPS50W Carbon and Low-alloy High-strength Steel Coil

ASME SA709/SA709M Grade HPS50W Carbon and Low-alloy High-strength Steel Coil Chemical Composition and Mechanical Property

C max Si Mn P max S max V max Nb Cu Ni Cr Mo Al N max

0.11

0.30–0.50

1.10–1.35

0.020

0.006

0.04–0.08 - 0.25–0.40 0.25–0.40 0.45–0.70 0.02–0.08 0.010–0.040 0.015
Grade Yield Strength (MPa) min. Tensile Strength (MPa) min. Elongation in 8 in. min. % Elongation in 2 in. min. %

SA709 HPS 50W

345 485 18 21

ASME SA709/SA709M Grade HPS50W Carbon and Low-alloy High-strength Steel Coil Application

SA709 Grade HPS50W carbon steel coil is used in the Construction of Bridges, Highway Construction and Other Engineering construction.

ASME SA709/SA709M Grade HPS50W Carbon and Low-alloy High-strength Steel Coil Other Name

ASME SA709/SA709M low-alloy high-strength steel, SA709 Grade HPS50W carbon steel coil, SA709 Grade HPS50W low-alloy high-strength steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
