13CrMo44 round bar belongs to alloy special structural steel.13CrMo44 round bar is usually used asHigh-temperature structural steel: Collectors, water boiler and superheater tubes (530oC).
13CrMo44 round bar
13CrMo44 round bar specification: 1mm to 3500mm.
13CrMo44 round bar Chemical Composition (in weight %):
|
C |
Si |
Mn |
Cr |
Mo |
Ni |
V |
W |
Others |
|
0.14 |
max. 0.40 |
0.55 |
0.98 |
0.60 |
- |
- |
- |
max. Cu = 0.30 |
13CrMo44 round bar Mechanical Properties in Hardened and Tempered Condition:
|
Diameter in mm |
0.2 % proof stress (N/mm2) |
Tensile strength (N/mm2) |
Elongation (%) |
Impact strength (J) |
|
up to 60 |
295 |
440-590 |
20 |
44 |
|
61-90 |
285 |
440-590 |
20 |
44 |
|
91-150 |
275 |
440-590 |
20 |
44 |
13CrMo44 round bar Physical properties (avarage values) at ambient temperature:
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.85
13CrMo44 round bar offered by BEBON has good quality to meet consumer's need. If need, we can reproduce the goods according to your requirements. If you are interested in 13CrMo44 round bar, please contact us.
