BS EN 10149-3 S420NC Hot Rolled Steel Coil

BS EN 10149-3 S420NC Hot Rolled Steel Coil Chemical Composition and Mechanical Property

C Mn Si P Alt Nb V Ti
max. max. max. max. max. min. max. max. max.
0.20 1.60 0.50 0.025 0.015 0.015 0.09 0.10 0.15

Grade

Mechanical Proeprties

Thickness

Yield

Tensile

Elongation

S420NC

mm

Min Mpa

Mpa

Min  %

T<3.0

420

530-670

18

T≥ 3.0

420

530-670

23

BS EN 10149-3 S420NC Hot Rolled Steel Coil Application

BS EN 10149-3 S420NC hot rolled steel coil has high yield strength and can be used for automobile frame.

BS EN 10149-3 S420NC Hot Rolled Steel Coil Other Name

BS EN 10149-3 S420NC hot rolled steel, BS EN 10149-3 S420NC hot rolled steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
