EN10028-3 P460NH High yield steel plate P460NH steel sheet HBW

EN10028-3 P460NH High yield steel plate is one of grade in En10028-3, which is non alloy and alloy steels with specified elevated temperature properties. P460NH steel sheet used above all for manufacturing boilers, pressure vessels and pipes transporting hot liquids.

P460NH High yield steel plate is widely applied in Petroleume,Chemical Factory and the Boilers domains,P460NH steel sheet also are made the Reacto,Heat Exchanger,Separator,Spherical Tank,the Tank of oil gas ,Nuclear reactor,pressure shell,High-pressure water pipe,Turbin shell and other equipments.

EN10028-3 P460NH High Yield steel plate Chemical composition(%)

C≤0.20 Si≤0.60 Mn:1.10-1.70 P≤0.025 S≤0.015 Al≥0.020 N≤0.025 Cr≤0.30 Cu≤0.70 Mo≤0.10 Nb≤0.05 Ni≤0.80 Ti≤0.030 V≤0.20

P460NH steel sheet Mechanical property

Yield srength Mpa :400-460 Tensile strength Mpa 540-730 Elongation A%:17

Reduction in cross section on fracture Z (%):21 Brinell hardness (HBW):333

As-Heat-Treated Condition: Solution and Aging, Annealing, Ausaging, Q+T,etc

P460NH High Yield steel plate Specification

Thickness: 3mm-600mm

Length: 3000mm-11000mm

Width: 1500mm-3000mm

Bebon is supplier of P460NH steel sheet in China.Thanks a lot for your interesting on our EN10028-3 P460NH. Any need in P460NH steel price, please feel free to contact us by email or calling to us. We will reply you in the first time.
