Q-BQB 310-2009 B510DL Automobile structure steel plate

Q-BQB 310-2009 B510DL Automobile structure steel plate

Q-BQB 310-2009 B510DL Automobile structure steel plate Chemical Composition and Mechanical Property

Grade C Si Mn P S Alt
B510DL ≤0.18 ≤0.30 ≤1.60 ≤0.025 ≤0.020 ≥0.010
Grade Down Yield Strength
MPa
Tensile Strength
MPa
Yield Ratio Elongation %
L0= 5.65√S0
180° Bending test
Apex diameter
B510DL ≥355 510~630 ≤0.80 ≥24 1a

Q-BQB 310-2009 B510DL Automobile structure steel plate Application

Q-BQB 310-2009 B510DL steel plate is mainly used for manufacture of automobile frames, beams, and other auto parts.

Q-BQB 310-2009 B510DL Automobile structure steel plate Other Name

Q-BQB 310-2009 B510DL steel plate, B510DL Automobile structure steel plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
