DIN17175 14MoV63 boiler steel pipe

DIN17175 14MoV63 boiler steel pipe Chemical Composition and Mechanical Property

Grade	Material	C	Si	Mn	P	S	Cr	Mo
14MoV63	1.7715	0.10-0.18	0.10-0.35	0.40-0.70	0.035	0.035	0.30-0.50	0.50-0.70

Grade	Material	Tensile strength N/mm2	Yield strength thickness,mm			Elongation (L=5do)		Notch impact energy
			≤16	>16≤40	>40≤60
			N/mm2 min
14MoV63	1.7715	460-610	320	320	310	20	18	41

DIN17175 14MoV63 boiler steel pipe Application

14MoV63 seamless tubes including tubes for headers of heat-resistant steels which are used in the construction of boilers,pipe-lines,pressure vessels and equipment

DIN17175 14MoV63 boiler steel pipe Other Name

DIN17175 14MoV63 boiler steel pipe, 14MoV63 boiler steel pipe, 14MoV63 boiler pipe, DIN17175 14MoV63 pipe

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
