Austenitic XM-19(S20910) stainless steel plate/coil

Austenitic XM-19(S20910) stainless steel plate/coil Chemical Composition and Mechanical Property

Grade	C	Mn	P	S	Si	Cr	Ni	Mo	N	Cu	Other Elements
XM-19(S20910)	0.06	4.00 - 6.00	0.040	0.030	0.75	20.5 - 23.5	11.5 - 13.5	1.50 - 3.00	0.2 - 0.40	---	Cb 0.10–0.30 V 0.10–0.30

Grade	Tensile Strength, min		Yield Strength, min		Elongation in 2 in. or 50 mm, min, %	Hardness, maxC		Cold Bend°D
Grade	ksi	MPa	ksi	MPa	Elongation in 2 in. or 50 mm, min, %	Brinell	Rockwell B	Cold Bend°D
XM-19(S20910)stainless steel coil	105	725	60	415	30	241	100	not required
XM-19(S20910)stainless steel plate	100	690	55	380	35	241	100	not required

Austenitic XM-19(S20910) stainless steel plate/coil Application

XM-19 (S20910) stainless steel plate/coil is widely used in petroleum, petrochemical, chemical, fertilizer, fuel recycling, pulp and paper, textile, food processing and marine industry.

Austenitic XM-19(S20910) stainless steel plate/coil Other Name

S20910 stainless steel plate/coil, Austenitic XM-19 stainless steel plate/coil, ASTM_A240 XM-19 stainless steel plate/coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
