022Cr24Ni17Mo5Mn6NbN GB/T4237 Austenitic stainless steel plate/coil

022Cr24Ni17Mo5Mn6NbN GB/T4237 Austenitic stainless steel plate/coil Chemical Composition and Mechanical Property

Grade	C	Si	Mn	P	S	Ni	Cr	Mo	Cu	N	Other
022Cr24Ni17Mo5Mn6NbN	0.030	1.00	5.00 - 7.00	0.030	0.010	16.00 - 18.00	23.00 - 25.00	4.00 - 5.00	---	0.40 - 0.60	Nb: 0.10

Grade	Non-proportional extension strength, R_p0.2/MPa ≥	Tensile strength, R_m/MPa ≥	Elongation, A/% ≥	Hardness
				HBW ≤	HRB ≤	HV ≤
022Cr24Ni17Mo5Mn6NbN	415	795	35	241	100	---

022Cr24Ni17Mo5Mn6NbN GB/T4237 Austenitic stainless steel plate/coil Application

GB/T4237 Austenitic 022Cr24Ni17Mo5Mn6NbN stainless steel plate/coil can be used in Oil machinery, acid corrosion equipment, pharmaceutical machinery, industrial boilers, chemical plants and urban environmental protection and other fields.

022Cr24Ni17Mo5Mn6NbN GB/T4237 Austenitic stainless steel plate/coil Other Name

GB/T4237 022Cr24Ni17Mo5Mn6NbN stainless steel plate, Austenitic 022Cr24Ni17Mo5Mn6NbN stainless steel coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
