High strength ASTM A514 grades steel plates

High strength ASTM A514 grades steel plates are conventional quenched and tempered steel.
ASTM A514 grades are signed for structural applications. ASTM A514 grades are available in a variety of chemistries: A, B, C, E, F, H, J, K, M, P, Q, S, and T. ASTM A514 grades steel plates are used where a weldable, machinable, very high strength steel is required to save weight or meet ultimate strength requirements.

Chemical composition of high strength ASTM A514 grades steel plates:

ASTM A514	C	Mn	P	S	SI	Ni	Cr	Mo	V	Ti	Zr	Cu	B
A514 Grade Q	0.14 -0.21	0.95 -1.30	≤0.035	≤0.04	0.15 -0.35	1.20 -1.50	1.00 -1.50	0.40 -0.60	0.03 -0.08	~	~	~	~
A514 Grade P	0.12 -0.21	0.45 -0.70	≤0.035	≤0.04	0.20 -0.35	1.20 -1.50	0.85 -1.20	0.44 -0.60	0.03 -0.08	~	~	~	0.001 -0.005
A514 Grade M	0.12 -0.21	0.45 -0.70	≤0.035	≤0.04	0.20 -0.35	1.20 -1.50		0.45 -0.60	~	~	~	~	0.001 -0.005
A514 Grade K	0.10 -0.20	1.10 -1.50	≤0.035	≤0.04	0.15 -0.30	~	~	0.45 -0.55	~	~	~	~	0.001 -0.005
A514 Grade J	0.12 -0.21	0.45 -0.70	≤0.035	≤0.04	0.20 -0.35	~	~	0.50 -0.65	~	~	~	~	0.001 -0.005
A514 Grade H	0.12 -0.21	0.95 -1.30	≤0.035	≤0.04	0.20 -0.35	0.30 -0.70	0.40 -0.65	0.20 -0.30	~	~	~	~	0.001 -0.005
A514 Grade F	0.10 -0.20	0.60 -1.00	≤0.035	≤0.04	0.15 -0.35	0.70 -1.00	0.40 -0.65	0.40 -0.60	~	~	~	~	0.0015 -0.006
A514 Grade E	0.12 -0.20	0.40 -0.70	≤0.035	≤0.04	0.20 -0.35	~	1.40 -2.00	0.40 -0.60	~	0.04 -0.10	~	0.20 -0.40	0.0015 -0.005
A514 Grade C	0.10 -0.20	1.10 -1.50	≤0.035	≤0.04	0.15 -0.30	~	~	0.20 -0.30	~	~	~	~	0.001 -0.005
A514 Grade B	0.12 -0.21	0.7 -1.0	≤0.035	≤0.04	0.2 -0.35	~	0.4 -0.65	0.15 -0.25	0.03 -0.08	0.01 -0.03	~	~	0.001 -0.005
A514 Grade A	0.15 -0.21	0.8 -1.1	≤0.035	≤0.04	0.4 -0.8	~	0.5 -0.8	0.18 -0.28	~	~	0.05 -0.15	~	0.0025 max

All of the high strength ASTM A514 grades steel plates have the same mechanical properties as below:

Grade	Thickness	Yield	Tensile	Elongation
ASTM A514	mm	Min Mpa	Mpa	Min %
	20	690	760-895	18
	20-65	690	760-895	18
	65-150	620	690-895	18

ASTM A514 grades steel plates are most commonly used as structural steel in building construction, for cranes, or other large machines supporting high loads.

BBN steel is professional high strength ASTM A514 grades steel plates supplier. For any information about ASTM A514 grades steel plates, such as ASTM A514 grades chemical composition, A514 steel plates mechanical property, high strength ASTM A514 steel specification, A514 grades steel data sheet, high strength ASTM A514 grades steel plates price, please feel free to consult BBN steel.
