ASTM A516 Gr.70 pressure vessel steel plate is an excellent choice for service in lower than ambient temperature applications. A516 Gr.70 steel plate has excellent notch toughness and is used in both pressure vessels and industrial boilers.
ASTM A516 Gr.70 pressure vessel steel plate Size:
Thickness: 3mm to 150mm
Width: 1,220mm to 4,200mm
Length: 5,000mm to 18,000mm
ASTM A516 Gr.70 pressure vessel steel plate advantage:
A516 Gr.70 steel offers greater tensile and yield strength when compared to ASTM A516 Gr. 65 and can operate in even lower temperature service.
Chemical Composition of ASTM A516 Gr.70 pressure vessel steel plate:
| C | Mn | P max | S max | Si max | ||||||
| Thickness | t < 12.5 mm |
12.5mm < t=50mm | 50mm < t ≤ 100mm | 100mm < t ≤ 200mm | t < 200 mm |
t < 12.5 mm |
t 12s.5 m |
|||
| A516 Grade 70 | 0.27 | 0.28 | 0.3 | 0.31 | 0.31 | 0.85-1.2 | 0.85-1.2 | 0.035 | 0.035 | 0.15-0.4 |
Mechanical Properties of ASTM A516 Gr.70 pressure vessel steel plate:
| Grade | Tensile Strength (ksi) | Tensile Strength (MPa) | Yield Strength (ksi) | Yield Strength (MPa) | Elongation in 200mm (%) | Elongation in 50mm (%) |
| A516 Grade 70 | 70-90 | 485-620 | 38 | 260 | 17 | 21 |
BBN steel supplies ASTM A516 Gr.70 pressure vessel steel plates at lower cost but the best service. As a result to that our export account today is in over 30 countries, including Iran, Saudi Arabia, United Arab Emirates, Singapore, Malaysia etc..
Just like you, 70% customers choose long-term cooperation with BBN steel not only for our good product and service quality, good reputation in the international market, but also for our experienced one-stop raw material supply and further steel processing!
