GB/T1591 Q420A Carbon and Low-alloy High-strength Steel Plate

GB/T1591 Q420A Carbon and Low-alloy High-strength Steel Plate

GB/T1591 Q420A Carbon and Low-alloy High-strength Steel Plate Chemical Composition and Mechanical Property

Grade C % Si % Mn  P % S %
Q420A ≤ 0.20 ≤ 0.55 1.00-1.70 ≤ 0.045 ≤ 0.045

Grade Thickness Yield Strength (Mpa) Tensile Strength Elongation(%) Impact Energy
(mm) (MPa) Min
Q420A ≤16 420 520-680 18 - -
  >16-35 400 520-680 18 - -
  >35 380 520-680 18 - -
The min impact energy is longitudinal energy

GB/T1591 Q420A Carbon and Low-alloy High-strength Steel Plate Application

GB/T1591 Q420A Steel Plate are used in Construction of Bridges, Highway Construction and Other Engineering construction

GB/T1591 Q420A Carbon and Low-alloy High-strength Steel Plate Other Name

GB/T1591 Q420A Carbon Structural Steel Plate, GB/T1591 Q420A High Strength Structural Steel Plate, GB/T1591 Q420A Carbon Steel plate, GB/T1591 Q420A Structural Steel Plate.

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
