EN10216-2 X10CrWMoVNb9-2 steel pipe

EN10216-2 X10CrWMoVNb9-2 steel pipe

EN10216-2 X10CrWMoVNb9-2 steel pipe Chemical Composition and Mechanical Property

EN10216-2 X10CrWMoVNb9-2 steel pipe exhibits excellent elevated-temperature strength and creep behavior up to 600 °C - 620 °C. Its 9 % chromium content offers good corrosion and oxidation resistance. In addition, the reduced weight of boiler and piping components resulting from the steel's superior performance compared with other standard steels allows higher resistance to thermal fatigue.

Chemical composition of EN10216-2 X10CrWMoVNb9-2 steel pipe:

C Si Mn P max Smax Cr Mo Ni AL Cu Nb V
0.7-0.13 ≤0.5 0.3-0.6 0.02 0.01 8.50-9.5 0.30-0.6 ≤0.40 ≤0.040 0.04-0.09 0.15-0.25

Mechanical properties of EN10216-2 X10CrWMoVNb9-2 steel pipe:

Yield strength Tensile Strength Elongation A min %
T≤16 16<T≤40 40<T≤60 60<T≤100 Rm I t
MPa MPa MPa MPa MPa
440 440 440 440 620-850 19 17

EN10216-2 X10CrWMoVNb9-2 steel pipe Application

EN10216-2 X10CrWMoVNb9-2 steel pipe is used for building boilers and pressure vessels’parts. EN10216-2 X10CrWMoVNb9-2 steel pipe has to be done Normalized plus Tempered heat treatment, Normalized at temperature 1040-1090℃. In fossil-fuelled power plants, EN10216-2 X10CrWMoVNb9-2 steel pipe is mainly used for high-temperature applications in superheater and reheater tubes, headers and steam piping.

EN10216-2 X10CrWMoVNb9-2 steel pipe Other Name

X10CrWMoVNb9-2 datasheet, X10CrWMoVNb9-2 mechanical properties, X10CrWMoVNb9-2 seamless steel pipes

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
