GL Grade E550 Shipbuilding Steel Plate Chemical Composition and Mechanical Property

C max Si max Mn P max S max N max.

0.20

0.55 1.70

0.025

0.025

0.020

Yield Strength (MPa) min. Tensile Strength (MPa) Elongation min. %
550 670-830 16

GL Grade E550 Shipbuilding Steel Plate Application

GL Grade E550 Shipbuilding steel plate is mainly used to Shipbuilding Project and Ocean Offshore Structural Project.

GL Grade E550 Shipbuilding Steel Plate Other Name

GL Grade E550 Shipbuilding steel plate,GL Grade E550 Ship Steel plate ,GL Grade E550 Marine Steel plate , GL Grade E550 Steel Plate .

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
