DIN 17102 TStE380 Automobile structure steel plate

DIN 17102 TStE380 Automobile structure steel plate

DIN 17102 TStE380 Automobile structure steel plate Chemical Composition and Mechanical Property

Grade C
Si Mn P
S
N
Al
Cr
Cu
Mo
Ni
Nb
Ti
V
Nb+Ti+V
TStE380 0.20 0.10~0.60 1.00~1.70 0.030 0.025 0.020 0.020 0.30 0.20 0.08 1.00 0.05 --- 0.20 0.22
Grades Tensile Strength Rm for
product thicknesses s,in mm
N/mm²
UpperYield StressReH²) for product thicknesses s,in mm
N/mm² min.
Elongation after fracture3)
(Lo=5do) % min.
Mandrel diameter for bend test 4), 5)
s≤70 70<s≤85 85<s≤100 100<s≤125 125<s≤150 s≤16 16<s≤35 35<s≤50 50<s≤60 60<s≤70 70<s≤85 85<s≤100 100<s≤125 125<s≤150 Longitudinal Transverse 6)
TStE380 500~650 490~640 480~630 470~620 460~610 380 375 365 355 345 335 325 315 305 20 2.5a 3.5a

DIN 17102 TStE380 Automobile structure steel plate Application

TStE380 structure steel plate can be used for shaft, piston type parts, automobiles, aircraft special wear-resistant parts.

DIN 17102 TStE380 Automobile structure steel plate Other Name

DIN 17102 TStE380 steel plate, TStE380 Automobile structure steel plate

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
Are you also interested in further steel processing (machining)?

Just like you, 70% customers choose long-term cooperation with BBN steel not only for our good product and service quality, good reputation in the international market, but also for our experienced one-stop raw material supply and further steel processing!

Fabrication and Machining Service24h Technical support
