DIN17102 StE255 Carbon and Low-alloy High-strength Steel Plate

DIN17102 StE255 Carbon and Low-alloy High-strength Steel Plate

DIN17102 StE255 Carbon and Low-alloy High-strength Steel Plate Chemical Composition and Mechanical Property

S% max N% max Al % max Cr % max Cu % max Mo % max Ni %  Nb % max
0.03 0.2 0.2 0.3 0.20 0.08 0.3 0.03
Tensile strength Mpa min Yield Strength Mpa Min
t≤70 70<t ≤ 85 85 <t ≤ 100 100 <t ≤ 125 125 <t ≤ 150 t≤16 16<t ≤ 35 35 <t ≤ 60 50 <t ≤ 60 60 <t ≤ 70 70<t ≤ 85 85 <t ≤ 100 100 <t ≤ 125 125 <t ≤ 150 Elongation % min
360-480 350-470 340-460 330-450 330-450 255 255 245 235 235 225 215 205 195 25



DIN17102 StE255 Carbon and Low-alloy High-strength Steel Plate Application

DIN17102 StE255 Steel Plates are used in Construction of Bridges, Highway Construction and Other Engineering construction

DIN17102 StE255 Carbon and Low-alloy High-strength Steel Plate Other Name

DIN17102 StE255 Carbon Structural Steel Plate, DIN17102 StE255 High Strength Structural Steel Plate, DIN17102 StE255 Carbon Steel plate, DIN17102 StE255 Structural Steel Plate.

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
