Austenitic XM-29(S24000) stainless steel plate/coil

Austenitic XM-29(S24000) stainless steel plate/coil Chemical Composition and Mechanical Property

Grade	C	Mn	P	S	Si	Cr	Ni	Mo	N	Cu	Other Elements
XM-29(S24000)	0.08	11.50 - 14.50	0.060	0.030	0.75	17.0 - 19.0	2.3 - 3.7	---	0.20 - 0.40	---	---

Grade	Tensile Strength, min		Yield Strength, min		Elongation in 2 in. or 50 mm, min, %	Hardness, maxC		Cold Bend°D
Grade	ksi	MPa	ksi	MPa	Elongation in 2 in. or 50 mm, min, %	Brinell	Rockwell B	Cold Bend°D
XM-29(S24000)stainless steel coil	100	690	60	415	40	241	100	not required
XM-29(S24000)stainless steel plate	100	690	55	380	40	241	100	not required

Austenitic XM-29(S24000) stainless steel plate/coil Application

ASTM A240 XM-29 stainless steel plate/coil applies to petroleum, chemical industry, electric power, boiler, high temperature resistant, low temperature resistant, corrosion resistant indestry.

Austenitic XM-29(S24000) stainless steel plate/coil Other Name

ASTM A240 XM-29 stainless steel plate/coil, UNS S24000 (XM-29) stainless steel plate/coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
