Austenitic 304H(S30409) stainless steel plate/coil

Austenitic 304H(S30409) stainless steel plate/coil Chemical Composition and Mechanical Property

Grade	C	Mn	P	S	Si	Cr	Ni	Mo	N	Cu	Other Elements
304H(S30409)	0.04 - 0.10	2.00	0.045	0.030	0.75	18.0 - 20.0	8.0 - 10.5	---	---	---	---

Grade	Tensile Strength, min		Yield Strength, min		Elongation in 2 in. or 50 mm, min, %	Hardness, maxC		Cold Bend°D
Grade	ksi	MPa	ksi	MPa	Elongation in 2 in. or 50 mm, min, %	Brinell	Rockwell B	Cold Bend°D
304H(S30409)	75	515	30	205	40	201	92	not required

Austenitic 304H(S30409) stainless steel plate/coil Application

SS304H stainless steel plate/coil is commonly used in the oil refining, gas and chemical industry and is used in industrial boilers, pressure vessels, heat exchangers, pipelines and condensers. The material is also used throughout the power generation industry.

Austenitic 304H(S30409) stainless steel plate/coil Other Name

ASTM_A240 304H stainless steel plate/coil, SS304H stainless steel plate/coil, UNS S30409 stainless steel plate/coil

Additional Condition

UT(Ultrasonic examination), AR(As Hot Rolled only), TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35), Charpy V-Notch Impact Test, The Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.

Other Terms

Packaging Details: Standard export seaworthy packing or as required.
Delivery Time: 30-50 days, 7 days for stock goods.
Loading Port: Shanghai ,Tianjin, Qingdao.
Offer Ability:5 000MT/Per Month.
MOQ: 1 Pcs.
