Brief introduction of Q420HD nuclear power steel

Q420HD carbon steel for nuclear power plants, used in chemical and nuclear industries. Q420HD is read as Q420 nuclear steel, Q is the acronym for yield, 420 is the yield value, and HD is the acronym for nuclear. Q420HD nuclear power steel executive standard: GB 30814.

Q420HD nuclear power steel heat treatment delivery status: hot rolling, hot rolling + tempering, normalizing, normalizing + tempering, quenching + tempering

Q420HD steel mechanical properties:

Thickness Mechanical properties
40-100mm Re (MPa) ≥420 When the yield is not obvious, use Rp0.2
Rm(MPa) 585-705
A50(%) ≥20
Impact temperature (℃) -30
Akv(J) ≥47 Horizontal

High temperature drawing of Q420HD nuclear power steel (will be displayed in MPA units):

Grade Thickness Tensile Test Tensile /MPa min
100 150 200 250 300 350
Q420HD ≤250mm ReH/MPa 380 360 345 335 325 310
Rm/MPa 530 530 530 530 530 515

Q420HD nuclear power steel chemical composition:

C Si Mn P S Ni Cr Mo Cu Nb V
≤0.18 0.15-0.5 0.9-1.5 ≤0.02 ≤0.015 ≤0.6 ≤0.3 ≤0.3 ≤0.35 ≤0.04 ≤0.07

Remarks for ingredients: when the thickness of the steel plate is greater than 65mm, the Mn content can be increased to 1.6 at the maximum; Nb+V≤0.08; when adding aluminum to refine grains, Als≥0.015 or Alt≥0.02. When adding Nb, V, Ti and other alloys element, the lower limit of Al content is not required.
